Output Type

CMOS

Output Load

15pF or specity

Oscillation Mode

Fundamental

SupplyVoltage(VDD)

3.3V

Frequency Range

50～200MHz

工作温度范围Operating Temperature Range

-10～+70°C,-40～+85°,orspecify

Storage Temperature Range

-55~+125°C

Voltage Vol(Max.)/Voh(Min.)

0.1 VDD/0.9VDD

Rise(Tr)/Fall(Tf) Time

5nS Max.

Supply Current

60 mA Max.

Symmetry

45～55%

Start-up Time

10mS Max

Absolute Puling Range(APR)

± 50ppm Min., or specify

Nominal Control Voltage

0.5VDD

Control Voltage Range

0~VDD

Linearity

10% Max

Phase Jitter(12KHz～20MHz)

1pS Max.
